Technical Specifications
# IR Diodes 8
#Beams 38
Detecting Height (mm) 15-367
Distance of Diodes (mm) 47.5
Operation Distance (mm) 4000
Response Time < 100 ms
Operating Temperature (°C) -20 / +65
Cable Length 2.5 m x 2
Alignment Tolarence (mm) Vertical +7- 15mm Horizontal +/- 3 mm
Profile Dimensions (mm) 11.64×21.45×450
Working In Sunlight
Technical Specifications
Operating Voltage 85-265 VAC
Power Consumption ≤ 4 W
Operating Temperature (°C) -20 / +65
Signal Output Relay (1 NC, 1 NO, 1 COM)
Nudging Output Relay (1 NC, 1 NO, 1 COM)
Buzzer Switch Off / On / Delayed
Dimensions (mm) 53.6 x 114.6 x 31
